Flowtera Pipe
1 / 5
Material Availability: Nikel 200, Nickel 201, Monel 400, Inconel 600, Inconel 601, Inconel 690, Inconel 617, Incoloy 800, Incoloy 625.
Standard Compliance: ASTM B162, ASTM B168, ASTM B127, ASTM B409, ASTM B443.
| Product Category | Standard | Material Grade |
|---|---|---|
| Nickel and Nickel Alloy Plate & Sheet | ASTM B162 | Nickel 200, 201 |
| ASTM F168 | Inconel 600, 601, 690, 602CA, 617 | |
| ASTM B127 | Monel 400 | |
| ASTM B409 | Incoloy 800, 800H | |
| ASTM B443 | Inconel 625 |
Features: Nickel is a versatile element that bonds with most alloys. It provides excellent heat and corrosion resistance, electrical and magnetic capabilities, and low expansion properties.
| Material | Ni | Fe | Cr | Al | Cu | C (Max) |
|---|---|---|---|---|---|---|
| Nickel 200 | 99.0 | 0.40 | -- | -- | 0.25 | 0.15 |
| Monel 400 | 63 | 2.5 | -- | -- | 28-34 | 0.3 |
| Inconel 600 | 72 | 6-10 | 14-17 | -- | 0.5 | 0.15 |
| Inconel 601 | 58-63 | Bal. | 21-25 | 1-1.7 | 1.0 | 0.10 |
| Inconel 625 | 58 | 5.0 | 20-23 | 0.4 | 0.5 | 0.1 |
| Grade | Tensile Strength (MPa) Min. | Yield Strength (MPa) Min. | Elongation (%) |
|---|---|---|---|
| Nickel 200 | 329 | 103 | 40 |
| Monel 400 | 483 | 193 | 35 |
| Inconel 600 | 552 | 241 | 30 |
| Inconel 601 | 552 | 207 | 30 |
| Incoloy 800 | 517 | 207 | 30 |
Every product undergoes rigorous testing to ensure performance: Ultrasonic Test, Eddy Current Test, Hydrostatic Test, Bend Test, Flaring Test, and more.
Our nickel alloy products are widely used in: Aviation, Marine Engineering, Shipbuilding, Medical Equipment, Chemical & Petrochemical Industries, Auto Manufacturing, and Construction.
